Scout-19 Off-Road Caravan
Suitable for
2 x Adults
Scout-19 Off-Road Caravan
Travel in Style. Live in Comfort. Our Most Luxurious Model Yet.
If you love camping and the travel lifestyle but don’t want to leave the luxuries of a solid roof, a large bed or a shower and toilet at home, look no further than the newest model in the Stoney Creek Campers range – the Scout-19 Off-Road Caravan.
Powered by the latest battery storage and solar setup and constructed with a our class-leading Gen 3 composite material, this caravan is perfect for the luxury travel experience, on and off-road. Adjust your Scout 19’s Airbagman air-suspension to match your load and road conditions, ensuring optimal stability and comfort on every journey.
The Scout-19 not only looks great but is designed to take on the most challenging tracks our amazing country has to offer. Fulfil that spirit of adventure in comfort and style.
Check out the key features the Scout-19 has to offer
1
2
3
4
5
6
7
8
1
Class-leading composite material. Lighter – Durable – Insulated.
2
Black Jack electric Jack
3
Slide out kitchen & prep area
4
Pantry & airbag control access
5
Electric awning
6
Fold out table
7
Airbag Man airbag suspension
8
Dual axle/mud terrain tyres/12 inch electric brakes
1
2
3
4
5
6
7
8
1
King style bed
2
Bedside and above-bed storage
3
Truma roof-mounted air-conditioning
4
Upright compressor fridge & freezer
5
Microwave
6
Thetford grill, oven & stove top with rangehood + sink
7
Plush interior seating & fold-out dinette
8
Ensuite with separate toilet & shower. Plenty of storage.
Technical Specifications & Optional Extras
| Item | Description |
|---|---|
| Overall Length (mm) | 7780 |
| Body Length (mm) | 5800 |
| Travel Height (mm) | 3000 |
| External Width (mm) | 2270 |
| Tare Weight (kg) | 2750 |
| ATM Weight (kg) | 3500 |
| Ball Weight @ tare (approx) (kg) | 145 |
| Measurements, weights and fit out inclusions are provided as a guide only and are not binding. With the inclusions of accessories these specifications may vary, it is advisable to discuss with your Stoney Creek representative. | |
| Toolbox (mm) | 1530 x 430 x 880 |
| Chassis, Suspension & Tyres | |
|---|---|
| Frame | Hot-dipped galvanised frame to protect against corrosion with 6″ x 2″ main members. |
| Wall Structure | Composite body/panelling providing superior strength, durability, insulation & looks. Hail and dent resistant. |
| Stone Guard | Front stone guard for protection in-line with front toolbox unit to protect van and tow vehicle against rock damage and ricocheting stones. |
| Suspension | 3500kg Tandem Axle with independent trailing arm suspension with dual shock absorbers and Airbag Man airbags. |
| Suspension Fixings | High tensile fixings. |
| Tyres | Mud Terrain 265/75R16 tyres (incl. two spares). |
| Wheel Rims | 16″ alloy rims for added strength and reduced weight (incl. two spares). |
| Tyre Pressure | Tyre pressure as per Stoney Creek Campers owners manual. |
| Stabilisation | Tuson sway control. |
| Trailer Plug Connection | Included 7-pin as standard (or alternative to suit vehicle). |
| Trailer Power Connection | Included Anderson plug. |
| Jockey Wheel | Black Jack Electric Jockey Stand. |
| Brakes | 12″ heavy-duty electric brakes with breakaway safety system and handbrake. |
| Chains | 2 x ADR compliant safety chains with ‘D’ shackles. |
| Coupling | Cruisemaster DO35 All-Terrain Coupling. |
| Doors & Hinges | High quality metal hinges (not plastic) bolted to the frame (not screwed). Adjustable latches on all external doors allow for easy adjustment. |
| Drop Down / Stabiliser Legs | Corner wind-down support legs (for stabilisation only). |
| Mud Flaps | Heavy duty, durable mud flaps. |
| Power & Electrical | |
|---|---|
| Solar Power System | Roof-mounted panel and regulator (700w). |
| Battery | 2 x 230 Ah Haidi Lithium Battery Bank featuring advanced LFP (Lithium Iron Phosphate) Technology, delivering high-capacity, deep-cycle power with exceptional efficiency, long lifespan and proven reliability for extended off-grid use. |
| Inverter | Renogy 3000W Pure Sine Wave Inverter for powerful and stable off-grid performance. |
| Power (240V) | Victron 240v power management system. |
| Mains Connector | Mains pressure to van. |
| Control Panel | All-in-one marine-style control panel with gauges for power and water. |
| DC-DC Charger | Victron DC-DC 30amp smart charger. |
| Fuses | Resettable fuses. |
| Water System & Ventilation | |
| Water Tanks (Fresh) | Dual 120-litre poly water tanks. |
| Water Tank (Grey) | 75-litre poly water tank. |
| Water Tank Protection | Chequer plate water tank guard. |
| Hot Water System | Truma gas & electric hot water system. |
| Water Filler | Dual secure & lockable water fill points. |
| Water Pumps | 12v pump and external switch. |
| Air Conditioning | Roof-mounted reverse-cycle air conditioning system. Inverter-compatible and can operate from the onboard battery system via the fitted inverter when off-grid. *Runtime will vary depending on battery, capacity, state of charge and overall system load. |
| Ventilation | Double-glazed windows with internal screens and block-out blinds. |
| Exterior | |
| Awning | Electric awning for basic set up in moments. |
| Kitchen | Pull out kitchen with cutlery drawer, utensil drawer, and slide-out bench extension with drop-down support legs. |
| Sink | Stainless steel basin with hot & cold mixer taps. |
| Pantry | Storage area beside external kitchen. |
| Gas Stove Top | High quality 3-Burner (with Flame Failure Device) including wind protection (Australian gas compliant). |
| Gas Bayonet | Exterior kitchen supplied with quick connect / release connection. |
| Gas Bottles | 2 x 3.7kg gas bottles positions provision plumbed and certified by a qualified gas technician. |
| Tunnel Boot | Twin offside storage areas |
| Jerry Can Holders | 2 x 20L Jerry can holders for additional fuel or water. |
| Table | In-built fold-out table. |
| Lighting | Rear, side and annexe LED lighting. |
| Entry Step | Power-operated single entry step. |
| Toolbox | Large A-frame toolbox for gas and generator (2Kva) storage. |
| Chequer Plate | Protective (black). |
| Interior | |
| Fire Extinguisher | 1kg Dry Powder Type Stored Pressure Fire Extinguisher. |
| Main Bed | Queen-size bed with comfortable, high quality memory foam mattress. |
| Kitchen | Thetford grill, oven and stove top with range hood. Sink with hot/cold water tap. |
| Ensuite / Bathroom Facilities | Full-size caravan en-sute with spacious shower, separate toilet and dedicated bathroom storage. |
| Dinette Table | Cafe-style fold-away dinette table. |
| Dinette Seating | Spacious dinette with durable finish and plush cushioning. |
| Fridge/Freezer | Upright compressor fridge (incl. freezer). |
| Pantry | Cupboard storage system. |
| Microwave | Internal microwave. |
| Flooring | Durable vinyl in a modern design. |
| Lighting | 12V reading lamps and LED strip lighting. |
| Storage | Under-bed and overhead storage compartments. |
| Skylight Hatch | Overhead skylight with in-built LEDs, fly screen and adjustable. |
| Entertainment & Technology | |
| Television | 22″ Smart TV. |
| Television Aerial | 12V Power-boosted aerial available for use with TV system. |
| Reversing Camera Kit | Rear-mounted rear vision camera (incl. dashboard monitor). |
| Stereo | Touchscreen entertainment unit & speaker system. |
| Item | Description |
|---|---|
| Awning (Upgrade) | Various options to extend and/or enclose awning space. |
| BBQ ARM | Power-coated galvanised steel arm with checker plate tray and universal drawbar mount. |
| Diesel Heater | 2kw diesel heater and fuel tank. Compact, fuel-efficient heating solution for off-grid comfort. |
Note: Images, videos, photos, plans and specifications are for illustrative purposes only, and the final product may vary. All details are subject to change. Please ensure you confirm all specifications, appearances, colours, extras etc. with your Stoney Creek Campers Representative before purchase.
