XL-FF Adventure Series Camper Trailer
Suitable for
4 x People
XL-FF Adventure Series Camper Trailer
Adventure Ready. Lightest in Class.
The XL-FF Adventure Camper Trailer is an industry leading lightweight camper trailer. This camper trailer is a forward-folding style and perfect for those seeking quick, easy getaways with maximised storage in a luxurious camper trailer.
Despite the compact size and weight, this camper has the ability to accomodate children with the dinette having the ability to convert to an additional bed. With so many perks, it’s no wonder this camper is so popular!
This camper trailer is perfect for quick getaways as it is lightweight, easy to set up and can be towed by small to medium SUVs and Sedans.
The XL-FF Camper Trailer has many benefits to enable your adventurous spirit such as a single piece 4″ chassis and independent trailing arm suspension, allowing you to venture off-road. Another standout feature is its impressive capacity to hold a 70l fridge, ensuring ample space to store food and beverages during long journeys. Furthermore, the XL-FF’s full external kitchen adds convenience, providing an easily accessible, undercover cooking space that can withstand the elements.
Being small and light doesn’t mean forgoing all the luxuries. It offers a pull-out kitchen with upgraded rollers, a hidden table extension, and a queen-sized bed with a luxe memory foam mattress.
Check out the key features the XL-FF has to offer
Technical Specifications & Optional Extras
| Item | Description |
|---|---|
| Body Length | 3350mm |
| Overall Length | 5150mm |
| Travel Height | 1500mm |
| External Width | 1735mm |
| Tare Weight | 1160kg |
| ATM Weight | 1500kg |
| Ball Weight @ tare (approx) | 110kg |
| Note: | Measurements, weights and fit out inclusions are provided as a guide only and are not binding. With the inclusions of accessories these specifications may vary, it is advisable to discuss with your Stoney Creek representative. |
| Item | Description |
|---|---|
| Trailer Chassis | 4″ x 2″ with rolled edges. Hot dipped galvanised A-frame helps protects the steel from corrosion. |
| Trailer Frame | Lightweight yet strong aluminium panels pop riveted to the frame and chassis. |
| Doors & Hinges | High quality hinges secured to the frame. All doors are sealed to prevent dust and water ingress. Adjustable latches are provided on all external doors for easy future adjustment. |
| Suspension Fixings | High tensile fixings. |
| Suspension | Upgraded independent trailing arm suspension engineered and designed with twin shock absorbers and coil springs. |
| Stone Guard | In-line with front toolbox / storage unit, to protect against stones and rocks damaging the camper and help prevent damage to the tow vehicle from stones bouncing back. |
| Jockey Wheel | AL-KO removable and adjustable jockey wheel. |
| Coupling | ADR-approved polyblock hitch (rated to 3.0 tonnes). |
| Trailer Plug Connection | Included 7-pin as standard (or alternative to suit vehicle). |
| Trailer Power Connection | Included Anderson plug. |
| Safety Chains | 2 x ADR complaint safety chains with ‘D’ shackle. |
| Brakes | 10″ heavy-duty electric brakes and handbrake. |
| Mud Flaps | Heavy duty, durable, mud flaps. |
| Wheel Rims | Alloy rims for strength and weight saving. |
| Tyres | Mud Terrain 235/75R15 tyres (inc. 1 x spare). |
| Tyre Pressure | Refer to our tyre pressure guide in your product manual. |
| Drop Down Legs | Corner wind-down supports for stabilisation only. |
| Item | Description |
|---|---|
| Battery | 100amp deep cycle AGM. |
| Fuses | Resettable fuses. |
| Control Panel | Marine style control panel with gauges for water, power with 12v and USB outlets. |
| Solar Wiring | Via Anderson plug |
| Gas Bottles | 2 x 4.5kg gas bottles provision connected and tested by a certified gas technician. |
| Gas Bayonet | Supplied (in kitchen) with quick connect / release connection. |
| Gas Cook Top | High quality gas stove top with 4 burners and wind protection (Australian gas compliant). |
| Fire Extinguisher | 1kg Dry Powder Type Stored Pressure Fire Extinguisher. |
| Jerry Can Holder | 20L jerry can holder for additional water. |
| Water Pump | 12v pump and external switch. |
| Water Tank | 80L poly water tank. |
| Water Filler | 1 x secure & lockable water fill points. |
| Hoses and Connections | 8mm NITTO fitting for hot and cold water allowing high pressure connectivity, with hoses supplied. |
| Sink | Hot and cold mixer with stainless steel basin. |
| Kitchen | Pull out kitchen with upgraded rollers, cutlery draw and hidden table extension. |
| Tent Canvas | Heavy-duty 14oz canvas, double-stitched for strength and durability, with waterproof treatment. |
| Tent Frame | Strong yet lightweight easy-style internal frame allowing basic setup in under 2 mins. |
| Poles | Lightweight smart ‘one-handed’ clamping system allows for simple extension and retraction. |
| Ventilation | Tent window flyscreens. Living room walls roll up. |
| External Lighting | Side LED. |
| Internal Lighting | Internal LED strip lights. |
| Internal Floor | Durable material with a modern design. |
| Internal Seating | Highly durable material with modern designs. Under seat storage is provided. |
| Bed 1 Main Front | Queen style bed with upgraded soft comfortable and high-quality memory foam mattress. |
| Bed 2 Lounge | Convert dining lounge to double style bed. |
| Storage | Lots of internal and external storage allows for fleixble packing options. |
| Annexe | Full annex with poles, walls and floor supplied. Guy ropes and steel pegs supplied. |
| Item | Description |
|---|---|
| Tap | Mains pressure to A-frame. |
| Fridge | 12/240v fridge freezer up to 70L. |
| Hot Water System | Hot water service – plumbed, with shower. |
| Solar Power System | Solar panel with regulator (200 & 300w available). |
| Television | 22″ LED TV |
| TV Aerial | Aerial available for use with TV system. |
| Stereo/DVD | Stereo & speaker system with built-in DCD player. |
| Battery Charger (Smart) | 240v management system. |
| DC to DC Charger | Intelligent DC to DC charger. |
How to set up your XL-FF Adventure Series Camper Trailer
Quick Setup
Annexe Setup
