Nugget-SF Off-Road Camper Trailer
Suitable for
2 x Adults
Nugget-SF Off-Road Camper Trailer
Rugged & Compact. For the Adventurous.
The Nugget-SF Off-Road Camper Trailer Generation 2 is the culmination of in depth design and structural advancements, bringing you the ultimate in a compact camper!
With a focus on comfort, quality and value, the Nugget-SF Gen 2 will get you there and back with confidence.
With newly updated premium stainless-steel kitchen facilities, including an electric tap, 2-burner gas stove and generous bench space, the Nugget-SF Off-Road Camper Trailer will make cooking in the great outdoors a dream.
Its compact size makes it ideal for taking anywhere, on or off road and then will store easily at home. Despite its small size, this camper still packs many of the luxuries of home, making short or long trips comfortable, simple and fun!
Check out the key features the Nugget-SF has to offer
Technical Specifications & Optional Extras
| Item | Description |
|---|---|
| Body Length (mm) | 1700 |
| Overall Length (mm) | 4250 |
| Travel Height (mm) | 1800 |
| External Width (mm) | 1850 |
| Tare Weight (kg) | 1140 |
| ATM Weight (kg) | 1600 |
| Ball Weight @ tare (approx) (kg) | 105 |
| Note: | Measurements, weights and fit out inclusions are provided as a guide only and are not binding. With the inclusions of accessories these specifications may vary, it is advisable to discuss with your Stoney Creek representative. |
| Chassis, Suspension & Tyres | |
|---|---|
| Trailer Structure | Superior powder-coated finish. Steel body, seam-welded (no angles or pop rivets) to ensure maximum strength, durability and prevention of dust and water intrusion. |
| Trailer A-Frame | 6″ x 2″ A-frame members with rolled edges for strength. Hot-dipped galvanised A-frame to protect the steel from corrosion. |
| Trailer Frame | External steel skin wraps around a structural post in corners and main door for structural strength. |
| Stone Guard | In-line with front toolbox to protect trailer and tow vehicle against rock damage and ricocheting stones. |
| Suspension | Upgraded independent trailing arm suspension engineered and designed with twin shock absorbers and coil springs. |
| Suspension Fixings | High tensile fixings. |
| Tyres | Mud Terrain 265/75R16 tyres (inc. spare). |
| Wheel Rims | Alloy rims for strength and weight saving. |
| Tyre Pressure | Refer to our tyre pressure guide in your product manual |
| Trailer Plug Connection | Included 7-pin as standard (or alternative to suit vehicle). |
| Trailer Power Connection | Included Anderson plug. |
| Jockey Wheel | Removable and adjustable jockey wheel. |
| Brakes | 12″ heavy-duty electric brakes and handbrake. |
| Chains | 2 x ADR compliant safety chains with ‘D’ shackle. |
| Coupling | ADR-approved poly block off-road hitch. |
| Doors & Hinges | High quality hinges secured to the frame. All doors are sealed to prevent dust and water ingress. Adjustable latches on all external doors for easy adjustment. |
| Drop-down Stabiliser Legs | Corner wind-down support legs (for stabilisation only). |
| Mud Flaps | Heavy duty, durable mud flaps. |
| Power & Electrical | |
|---|---|
| Solar Wiring | Via Anderson plug. |
| Battery | 2 x 100amp lithium batteries. |
| Battery Charger | 12/240v management system. |
| Control Panel | Marine-style control panel with water gauges, 12v power and two USB outlets. |
| DC-DC Charger | Intelligent DC to DC charger. |
| Fuses | Resettable fuses. |
| Water System & Ventilation | |
| Water Tank | 80L poly tank. |
| Hot Water System | Plumbed hot water system with shower. |
| Water Filler | Secure & lockable water fill point. |
| Water Pumps | 12v pump and external switch. |
| Hoses and Connections | 8mm NITTO fitting for water allowing high pressure connectivity (hoses supplied). |
| Ventilation | Tent window flyscreens. |
| Exterior | |
| Tent Frame | Strong, lightweight easy-style internal frame allowing basic setup in under two minutes. |
| Tent Canvas | Heavy-duty 14oz canvas, strong and durable double-stitching with waterproof treatment. |
| Annexe | Full annex with poles, walls and floor supplied. Guy ropes and steel pegs supplied. |
| Poles | Smart, lightweight ‘one-handed’ clamping system for simple extension and retraction. |
| Kitchen | Pull-out kitchen with utensil drawer and slide-out bench extension. |
| Sink | Mixer tap with stainless steel basin. |
| Gas Stove Top | High quality gas stove top with 2 burners and wind protection (Australian gas compliant). |
| Gas Bayonet | Supplied (in kitchen) with quick connect / release connection. |
| Gas Bottles | 2 x 4.5kg gas bottle positions provision plumbed and certified by a qualified gas technician. |
| Jerry Can Holder | Dual 20L jerry can holders for additional fuel or water. |
| Lighting | Side LED. |
| Interior | |
| Fire Extinguisher | 1kg Dry Powder Type Stored Pressure Fire Extinguisher. |
| Main Bed | Queen-style bed with comfortable, high-quality mattress. |
| Item | Description |
|---|---|
| Mains Connector | Mains pressure to A-frame. |
| Fridge | 12/240v fridge freezer up to 70L. |
| Solar System | 200w – 300w solar panel with regulator. |
| Television | 19” LED TV. |
| TV Aerial | Aerial available for use with TV system. |
| Coupling (upgrade) | Cruisemaster DO35 All-Terrain coupling. |
Note: Images, videos, photos, plans and specifications are for illustrative purposes only, and the final product may vary. All details are subject to change. Please ensure you confirm all specifications, appearances, colours, extras etc. with your Stoney Creek Campers Representative before purchase.
